240 Version - EK-Quantum Kinetic3 FLT Body PWM D-RGB Installation Manual

12
11
9
10
1
4
5
2

240 VERSION

Technical Specification:
- Dimensions: (L x H x W) – 120 x 238.5 x 47.5 mm
- D-RGB cable length: 500 mm
- D-RGB LED count: 14
- D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground)
15
7
Position EAN
6
13
8
3
14
- 10 -
Description
1 107330 TOP Plexi - Block FLT 240
2 107336 TOP Plexi - Lid FLT 240
3 9040 Screw M3 x 28 DIN7991
4 102639 EK-Plug G1/4
5 3831109834282 Plug Cover
6 107320 LED Cover
7 107339 Mylar Label
8 107347 OR - FLT 120
9 100663 EK Badge
10 5154 OR 52 x 3
11 105913 Pump holder
12 8311 Screw M4 x 20 DIN7984
13 107344 OR - Kinetic
14 8312 Screw M4 x 16 DIN7991
15 102711 LED Strip
Quantity
1
1
2
9
9
1
1
1
1
1
1
4
FLT 240 1
3
17
1
