RESERVOIR DIMENSIONS

92 Version:
92 mm
17.5 mm
14 mm
31.5 mm
47.5 mm
120 Version:
120 mm
14 mm 17.5 mm
31.5 mm
105 mm
13.5 mm
82.5 mm
14 mm
105 mm
47.5 mm
140 Version:
140 mm
14 mm
125 mm
- 5 -
17.5 mm 14 mm
31.5 mm 125 mm
47.5 mm
