140 Version - EK-Quantum Kinetic3 FLT Body PWM D-RGB Installation Manual

8
7
6
10
11
1

140 VERSION

Technical Specification:
- Dimensions: (L x H x W) – 140 x 238.5 x 47.5 mm
- D-RGB cable length: 500 mm
- D-RGB LED count: 14
- D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground)
3
Position EAN
14
9
5
13
2
4
12
- 9 -
Description
1 107329 TOP Plexi - Block FLT 140
2 107335 TOP Plexi - Lid FLT 140
3 107339 Mylar Label
4 9040 Screw M3 x 28 DIN7991
5 100663 EK Badge
6 5154 OR 52 x 3
7 105913 Pump holder
8 8311 Screw M4 x 20 DIN7984
9 107316 Pump holder
10 3831109834282 Plug Cover
11 102639 EK-Plug G1/4
12 8312 Screw M4 x 16 DIN7991
13 107343 OR - FLT 140
14 103155 LED Strip
Quantity
1
1
1
2
1
1
1
4
1
7
7
12
1
1
