INSTALLING EK-QUANTUM KINETIC FLT WITH SUPPLIED MOUNTS
3
EK provides a Kinetic
washers and screws to allow the installation of the reservoir onto
fans, radiators or PC cases. The bracket can be positioned across
any pair of mounting holes in various orientations.
Example of EK-Quantum Kinetic
radiator:
STEP 1
Screw the bracket on the radiator using supplied four (4)M4x4
DIN7984 screws using 2.5 mm allen key.
For this step, you will need:
Allen Key 2.5 mm
M4 x 4
DIN7984
SCREW
MOUNT
BRACKET
140 (2pcs)
STEP 1
- 18 -
Side Mount Bracket along with M4 nuts,
3
FLT 240 mounted on the
3
M4 x 4 7984DIN Mount Bracket
Screw (4pcs) 140 (2pcs)
