TECHNICAL SPECIFICATIONS AND PRODUCT PARTS

1
2
3
4
6
7
5
8
9
10
11
12
13
Technical Specification:
- Dimensions (L x H x W): 212.5 x 121.5 x 40 mm
- D-RGB (Addressable RGB) Cable Length: 500 mm
- D-RGB LED Count: 24
- D-RGB Connector: Standard 3-Pin (+5V, Data, Blocked, Ground)
Position EAN
1 100663
104128
2
104129
3 104124
4 104126
5 100815
6 104131
9041N
7
9041
8 5092
9041N
9
14
9041
10 104133
11 5158
12 102639
13 104123
103398
14
103397
- 6 -
Description
EK Badge
Top plate cover (Black elox)
Top plate cover (Natural elox)
Top plexi
Main O-ring
LED Strip
Coldplate (Nickel)
M3 x 11 DIN7991 (Ni)
M3 x 11 DIN7991
OR 12 x 1.5
M3 x 11 DIN7991 (Ni)
M3 x 11 DIN7991
Terminal insert (Nickel)
OR 35 x 1.5
EK-Plug G1/4
AB Terminal
Terminal screw (Black Chrome)
Terminal screw (Nickel)
Quantity
1
1
1
1
1
1
13
2
2
1
1
2
1
2
