Mec 1330SE Service & Parts Manual page 73

Section 15 - Platform
Item Part Number
1
2
--
--
--
--
3
--
--
--
--
4
--
--
--
--
5
--
6
--
7
--
--
8
9
10
11
Page 69
41632 Decal, Platform Control Panel
41149 Joystick
43621 Function Enable Switch
41150 Joystick Cover
43622 Joystick Steer Switch
43623 Switch Boot
41152 Coil Cord
43624 Housing
Male Insert
43625
43626 Male Contacts
43627 Cable Gland
43999 Platform Control Box Harness (To Serial #16308570)
46763 Platform Control Box Harness (From Serial #16308571)
43628 Hood
Female Insert
43629
43630 Female Contacts
43627 Cable Gland
41568 Alarm
43631 Alarm Nut
41156 Main Board
41155 Button
41157 Emergency Stop Switch
43632 Red Mushroom Head
43633 Base With 1 NC Contact
42915 Decal, Emergency Stop Panel
43634 Enclosure
43635 Cover Bottom
41271 Replacement Connector, Gray
1330SE - Service & Parts Manual - 95834
Description
October 2024
Qty.
1
1
1
1
1
1
1
1
1
5
1
1
1
1
1
5
1
1
1
1
4
1
1
1
1
1
1
1
