Mec 1330SE Service & Parts Manual page 49

Section 13 - Chassis
Item Part Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Page 45
41207 Pothole Guard Weldment (To Serial #16308570)
46749 Pothole Guard Weldment (From Serial #16308571)
50430 Screw HHCS M10-1.50 × 45
41211 Pin
41208 Pothole Guard Weldment (To Serial #16308570)
46750 Pothole Guard Weldment (From Serial #16308571)
41210 Bearing
41209 Pin
50311 Nut NNYL M10-1.50 Flange
41213 Pothole Link Plate
41214 Bearing
53349 Nut NNYL M14-2.00 Flange
41212 Gas Shock Strut
41215 Gas Shock
53283 Set Screw M05-0.80 × 10 Cone Point
41319 Linkage Weldment
41216 Pin
41217 Roller
41320 Linkage Weldment
44609 Pothole Guide
41203 Bearing
44610 Seal
41204 Pothole Hole Pusher Pin
44007 Adjusting Washer 2
44008 Adjusting Washer 3
41205 Pothole Hole Pusher Rod
47376 Pivot Pin, Pothole Weld
1330SE - Service & Parts Manual - 95834
Description
October 2024
Qty.
1
1
4
2
1
1
4
4
8
2
8
6
2
2
2
1
2
2
1
1
4
2
2
2
2
2
1
