Mec 1330SE Service & Parts Manual page 67

Section 15 - Platform
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Page 63
Part Number
44582 Left Main Rail
44583 Right Main Rail
43618 Circlips
41131 Bearing
41269 Roller
53358 Screw HHCS M08-1.25 × 50 Flange
50313 Nut NNYL M08-1.25 Flange
53275 Screw CSCS M08-1.25 × 45
41360 Roller Bracket
41272 Main Deck Weldment
53276 Screw PHMS M04-0.70 × 8
41134 Clip
53273 Screw HHCS M06-1.00 × 14 Serrated Flange
41127 Hinge A
41128 Hinge B
41273 Water-Proof Joint
41046 Bearing
41275 Sheath
42462 Washer
53359 Screw HHCS M08-1.25 × 55 Flange
44584 Entry Gate
53360 Screw HHCS M06-1.00 × 45 Flange
41277 Spring
41278 Latch Handle
50568 Nut NNYL M06-1.00 Flange
1330SE - Service & Parts Manual - 95834
Description
October 2024
Qty.
1
1
2
2
2
4
8
8
2
1
2
2
12
1
1
1
2
1
4
4
1
1
1
1
1
