Section 9 - Transport and Lifting Instructions

Free-Wheel Configuration for Winching or Towing

Free-Wheel Configuration for Winching or Towing
ART_6091
DANGER
The machine can be winched or towed short distances at speeds not to exceed 2.5mph (4km/h).
Before towing or winching the machine, it is necessary to release the brakes. Reset the brakes after
towing or winching.
Disengage Brakes Before Towing Or Winching
1. Chock the wheels.
2. Turn the Key Switch to the Off position (pushed in).
3. Pull the Red Emergency Stop button out to the On
position (pulled out) at both the ground and platform
controls.
4. At the Ground Controls panel, push and hold the red
rocker switch to the left & push down and hold the
Platform Lift Switch.
5. An alarm will sound, signaling that the brakes have
been released.
Resetting Brakes
Push in the Emergency Stop button or turn the Key Switch to the Off position to reset the brakes.
ART_6091
WARNING
Page 12
RUNAWAY HAZARD!
AFTER RELEASING THE BRAKES THERE IS NOTHING TO STOP
MACHINE TRAVEL. MACHINE WILL ROLL FREELY ON SLOPES.
ALWAYS CHOCK THE WHEELS BEFORE MANUALLY RELEASING THE
BRAKES.
BE SURE THAT THE BRAKES ARE ENGAGED BEFORE REMOVING THE
WHEEL CHOCKS.
1330SE - Service & Parts Manual - 95834
October 2024
Push Down
& Hold
Push red rocker
1
switch to left
Turn to
Ground
Reset E-Stop
2
(pull out)
Art_4998
