Mec 1330SE Service & Parts Manual page 43

Section 13 - Chassis
Item
1
--
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Page 39
Part Number
41223 Steer Cylinder Assembly
41594 Seal Kit
41298 Straight Fitting
46735 Cover
41794 Screw
41322 Cotter Pin
41321 Pin
41225 Bearing
43564 Washer
41210 Bearing
46736 Steer Yoke Weldment
46737 Wheel
46738 Nut
46739 Washer
41230 Bearing Cover
53269 Screw CSCS M05-0.80 × 16
43563 Cotter Pin
44648 Key
44650 Wheel Shaft
41024 Bearing
41234 Connection Plate
50429 Screw HHCS M10-1.50 × 25 Serrated Flange
41327 Washer
53347 Castle Nut M16 × 1.50
41328 Cap
53282 Screw CSCS M08-1.25 × 20
46740 Steer Yoke Weldment
41222 Bearing
41221 Tie Rod
50311 Nut NNYL M10-1.50 Flange
41199 Washer
41202 Bearing
1330SE - Service & Parts Manual - 95834
Description
October 2024
Qty.
1
1
2
2
2
4
2
4
2
4
1
2
2
2
2
8
2
2
2
4
2
12
2
2
2
12
1
2
1
2
2
4
