Section 4 - Specifications

Maximum
Working Height*
Maximum
Platform Height
Maximum Drive Height
Stowed Height
Guardrail Height
Maximum
Occupants
Manual Force
Toeboard Height
Machine Weight** (Unloaded)
Maximum Lift Capacity
Deck Extension Capacity
Length-Stowed
Platform Length
Width (Overall)
Platform Width (Outside)
Wheel Base
Turning Radius - Inside
Ground
Clearance
Drive Speed
(Proportional)
Gradability
Maximum Side Slope - Stowed
Ground Pressure/Wheel
Maximum Wheel Load
Occupied Floor Pressure
Maximum Operating Wind Speed
Tire Size
Lug Nut Torque
Hydraulic Pressure
Power System Voltage
Battery Charger
Batteries
Chassis Inclination
Meets requirements of ANSI A92.20-2020 and CSA B354.6-2019.
*Working Height adds 6 feet (2 meters) to platform height.
**Weight may increase with certain options.
Page 7

Specifications

Specifications
Indoor
Outdoor
Indoor
Outdoor
Top Guardrail
Platform Floor
Indoor
Outdoor
Indoor
Outdoor
Overall
Ladder Removed
Extended
Retracted
Stowed
Elevated
Stowed
Raised/Extended
19 ft-lb (25.5Nm), secured with cotter pin
Input
Output
1330SE - Service & Parts Manual - 95834
19 feet 6 meters
16 feet 4.9 meters
13 feet 3.9 meters
10 feet 3 meters
13 feet 4 meters
74 inches 1.9 meters
35 inches 0.9 meters
39 inches 1 meters
2 Person
1 Person
90lbs 400N
45lbs 200N
6 inches 15 centimeters
2,050lbs 930kg
500lbs 227kg
1 Person
58 inches 1.5 meters
51 inches 1.3 meters
75 inches 1.9 meters
51 inches 1.3 meters
30 inches 76 centimeters
27.5 inches 70 centimeters
41 inches 1 meter
18 inches 45 centimeters
2.5 inches 6 centimeters
0.6 inches 1.5 centimeters
0-2.5mph 0-4.0km/h
0-0.7mph 0-1.1km/h
25% (14°)
5°
112psi 7.9kg/cm
750lbs 340kg
234psf 1,138kg/m
28mph 12.5 m/sec (45 km/h)
9×3 inch 230×80mm
2,250 psi 155 bar
24 Volt DC
110-230 V AC, 50-60 Hz
24 Volt DC
Two 12-Volt deep cycle; 85Ah
1.5 Side , 3.0 Inline
October 2024
2
2
