Section 9 - Transport and Lifting Instructions
ART_6091
DANGER
The following are needed to safely lift and support the machine;
• A jack with a lifting capacity of two (2) tons or more.
• Jack stands with a rating of two (2) tons or more.
To Raise the Machine
1. Move machine to a firm level surface capable of supporting the weight of the machine.
2. Chock tires on one end of machine and raise the other end of machine.
3. Position a jack at the end of the machine to be lifted, under a solid lifting point in the center of
the frame.
4. Raise the machine and place two (2) suitable jack stands under solid support points at the outer
ends of the frame.
5. Lower the machine to rest on the jack stands and inspect for stability.
To Lower the Machine
1. Raise machine slightly and remove jack stands.
2. Lower the machine and remove the jack.
3. Remove chocks.
Page 13

Lift and Support the Machine

DEATH OR SERIOUS PERSONAL INJURY MAY RESULT FROM THE USE
OF SUBSTANDARD LIFTING DEVICES AND/OR JACK STANDS. ENSURE
THAT ALL LIFTING DEVICES AND JACK STANDS ARE OF ADEQUATE
CAPACITY AND IN GOOD WORKING CONDITION BEFORE USE.
