Mec 1330SE Service & Parts Manual page 51

Section 13 - Chassis
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
Page 47
Part Number
REF Hydraulic Power Unit (Refer to page 50)
41413 Nut
44860 Straight Fitting
43639 Elbow
41296 Straight Fitting
44053 Protect Cover
53350 Wing Nut M06-1.00
41330 Battery
44039 Towline
53352 Screw CSCS M06-1.00 × 10
44040 Towline Bracket
53273 Screw HHCS M06-1.00 × 14 Serrated Flange
REF Motor Controller Assembly (Refer to page 52)
53038 WSHR M05 Standard Flat Washer
53043 WSHR M05 Spring Washer
50359 Screw SHCS M05-0.80 × 16
41075 Horn
53351 Screw PHMS M05-0.80 × 16
53281 Nut NNYL M05-0.80 Flange
43977 Latch
53264 Screw PHMS M06-1.00 × 20
53353 Screw PHMS M06-1.00 × 25
50568 Nut NNYL M06-1.00 Flange
REF Ground Control Assembly (Refer to page 54)
53348 Screw THMS M04-0.70 × 10
41575 Plug
53263 Screw THMS M04-0.70 × 8
44051 Battery Tray Weldment
53222 Screw PHMS M05-0.80 × 8
42904 Charger
41255 Glide Track
53225 Screw CSCS M10-1.50 × 30
41337 Bracket
50002 WSHR M10 Standard Flat Washer
53054 WSHR M10 Spring Washer
50127 Screw SHCS M10-1.50 × 30
REF - Reference
1330SE - Service & Parts Manual - 95834
Description
October 2024
Qty.
1
1
1
3
2
1
4
2
1
4
1
2
1
8
8
4
1
8
8
2
4
4
8
1
8
1
2
1
4
1
2
2
1
2
2
2
