Mec 1330SE Service & Parts Manual page 59

Section 13 - Chassis
Item
1
2
3
4
5
6
7
8
9
10
11
12
--
13
14
15
--
--
16
--
--
--
Page 55
Part Number
53171 Screw SHCS M05-0.80 × 30
43904 Decal, Ground Control Panel (1330SE)
44052 Ground Control Panel Weldment
41070 Hour Meter (To Serial #16308570)
46754 Hour Meter (From Serial #16308571)
43989 Controller
50284 WSHR M04 Standard Flat Washer
50285 Nut NNYL M04 × 0.70
41334 Relay
44054 Sleeve Pipe
42071 Power Switch
41419 Toggle Switch
41418 Key Switch
91574 Key
Indicator
41421
43991 Brake Release Switch
41422 Emergency Stop Switch
43098 Red Mushroom Head
43097 Base With 1 NC Contact
43992 Select Switch (To Serial #16308570)
46755 Select Switch (From Serial #16308571)
43993 Select Switch Head
43994 Base With 1 NO Contact
43096 NC Contact
1330SE - Service & Parts Manual - 95834
Description
October 2024
Qty.
2
1
1
1
1
1
4
4
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
