Mec 1330SE Service & Parts Manual page 63

Section 13 - Chassis
Item Part Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
Page 59
53265 Screw THMS M05-0.80 × 10
44041 Frame Weldment
41308 Cover
41311 Cover
41257 Bearing
41312 Sensor Cover
53223 Screw THMS M05-0.80 × 16
44615 Ladder
50031 Screw HHCS M08-1.25 × 25
53055 WSHR M08 Spring Washer
50001 WSHR M08 Standard Flat Washer
41194 Sensor Bracket
41195 Rotary Sensor
53065 Screw SHCS M04-0.70 × 30
53062 WSHR M04 Spring Washer
50284 WSHR M04 Standard Flat Washer
41309 Beacon Cover
53038 WSHR M05 Standard Flat Washer
53356 Screw SHCS M05-0.80 × 25
46264 Beacon
53281 Nut NNYL M05-0.80 Flange
42406 Beacon Bracket
53173 Screw SHCS M05-0.80 × 10
WSHR M05 Serrated Lock Washer Internal Teeth
53425
53426 WSHR M05 Serrated Lock Washer External Teeth
43978 Lock Clasp
53273 Screw HHCS M06-1.00 × 14 Serrated Flange
41003 Ground Strap
53113 Screw SHCS M04-0.70 × 16
41197 Limit Switch
41315 Switch Cover
50423 Screw SHCS M04-0.70 × 12
41198 Switch Cover
50289 Screw HHCS M06-1.00 × 40
42403 Sensor Bracket
50568 Nut NNYL M06-1.00 Flange
41098 Tilt Sensor
53043 WSHR M05 Spring Washer
1330SE - Service & Parts Manual - 95834
Description
October 2024
Qty.
9
1
1
1
2
1
2
1
4
4
4
1
1
6
6
6
1
4
2
1
2
1
8
6
6
2
1
1
4
2
1
4
1
2
1
2
1
2
