Mec 1330SE Service & Parts Manual page 61

Section 13 - Chassis
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
Page 57
Part Number
44041 Frame Weldment
53265 Screw THMS M05-0.80 × 10
41308 Cover
41311 Cover
41257 Bearing
41312 Sensor Cover
53223 Screw THMS M05-0.80 × 16
41193 Ladder
50031 Screw HHCS M08-1.25 × 25
53055 WSHR M08 Spring Washer
50001 WSHR M08 Standard Flat Washer
41194 Sensor Bracket
41195 Rotary Sensor
50284 WSHR M04 Standard Flat Washer
53062 WSHR M04 Spring Washer
53065 Screw SHCS M04-0.70 × 30
53356 Screw SHCS M05-0.80 × 25
53038 WSHR M05 Standard Flat Washer
41309 Beacon Cover
41310 Beacon
42406 Beacon Bracket
53281 Nut NNYL M05-0.80 Flange
53173 Screw SHCS M05-0.80 × 10
WSHR M05 Serrated Lock Washer Internal Teeth
53425
53426 WSHR M05 Serrated Lock Washer External Teeth
43978 Lock Clasp
53113 Screw SHCS M04-0.70 × 16
41197 Limit Switch
41315 Switch Cover
50423 Screw SHCS M04-0.70 × 12
41198 Switch Cover
50289 Screw HHCS M06-1.00 × 40
42403 Sensor Bracket
50568 Nut NNYL M06-1.00 Flange
41098 Tilt Sensor
53043 WSHR M05 Spring Washer
1330SE - Service & Parts Manual - 95834
Description
October 2024
Qty.
1
9
1
1
2
1
2
1
4
4
4
1
1
6
6
6
2
4
1
1
1
2
8
6
6
2
4
2
1
4
1
2
1
2
1
2
