CHAPTER
2.
OESCRIPTION
ISDN 7505
voic€ Teminal (wirhout Display)
Thjs multi-appearance voice terminal (Figure 2-17) comes equipped with the following:
.
Handset
.
Handset
cord and mounting cord
.
Touch-tone dial
.
Message light
.
Volume
control (adjusts the voiume of both the tone ringer and the various speakers)
.
Built-in speaker
.
Ten fixed feature buttons
l!
El
-
Used
to turn the speakerphone or SPOKESMAN speaker on or off.
lFl
-
Used
to set up a conference call between 3 or
more parties. Also used
with the
shift Select button to select
a
personal ring pattern.
E) -
Used
to end a
call or to drop the last party added to a conference call.
Also
used
with the
shift selecl
button
to self-test lhe terminal.
fEl -
Used to
transfer a
call
to anolher
line.
@ -
Used
to put
a
call
on
hold.
@) -
Used
to
select a second level
of
features on
lhe Redial, Drcp Test.
ftansler
Clock, Conlerence Ring, and Data feature buttons.
@J
-
Used
to
redial
the last number dialed.
@ -
Used
to
prevent a caller
lrom
hearing your local conversation.
l;i;]
-
Used
lo
increase
or
decrease
the
volume
of
the
handset
speaker,
speakerphone speaker, or SPOKESMAN speaker during a
call.
When
the terminal
is
not in use, it is used to adjust the ringer volume.
.
Ten appearance/feature buftons
Customer-designated
-
Used for {eatures or for
multiple appearances
of
one
or
more extensions, and labeled with feature name or extension number.
Each
of the
'10
buttons has a pair of red and green (in-use and status) indicator lights
located beside the button.
When one
of
the buttons js used as
a
Oata button, only 9
buttons are
left for
ca
appearance/f eature use.
210
