Raption Series Quick Start Installation Manual
Notes:
1- It is highly recomened to move the power supply wiring insertion to the right, in order to
aling the cables with its connection to the terminal block.
2- Use the M10 screw and washer provided in order to connect the electric terminals. The
maximum tightening torque is 20Nm.
3- Use a M10 metallic electric terminal aligned with the required cable cross section
according to the power of the Charge Point (Max. 150 mm2). See this requirement in the
data sheet.
4- After connecting the power supply, place shield protection over the connection terminals.
MODEL SPECIFICATIONS
Minimum
recommended
cable cross
sectional area *
Maximum cable
cross sectional
area **
(*) This is the minimum recommended cable cross sectional area for the maximum AC input
current (see datasheet) using multi-core copper cables with three loaded conductors for in-
stallations in conduit in a thermally insulated wall (A2 method according to IEC-60364-5-52).
Final cross section might be different if installation method is another one, in any case, it
has to be calculated by the installer, taking into account the cable materials, the conditions
of installation and distances.
(**) This is the maximum cable cross sectional area accepted by the Main circuit breaker
18
CCS CHA CCS CHA
T2C32 T2S32
95 mm2 95 mm2
150 mm2 150 mm2
CCS CHA CCS T2S32
70 mm2 95 mm2
150 mm2 150 mm2
CCS
CCS
T2C32
95 mm2 70 mm2
150 mm2 150 mm2
.
