Raption Series Quick Start Installation Manual
MODEL SPECIFICATIONS
Minimum
recommended
cable cross
sectional area *
Maximum cable
cross sectional
area **
(*) This is the minimum recommended cable cross sectional area for the maximum AC
input current (see datasheet) using multi-core copper cables with three loaded conduc-
tors for installations in conduit in a thermally insulated wall (A2 method according to
IEC-60364-5-52).
The final cross section might be different if the installation method is another one, in any
case, it has to be calculated by the installer, taking into account the cable materials, the
conditions of installation and distances.
(**) This is the maximum cable cross sectional area accepted by the Main circuit breaker
16
CCS1 CHA
480/277 V 208/240 V
(III) (II)
25 mm2 10 mm2
95 mm2 95 mm2
CCS1 T1C32
480/277 V 208/240 V
(III) (II)
25 mm2 10 mm2
95 mm2 95 mm2
CCS1 CHA T1C32
480/277 V 208/240
(III) V (II)
25 mm2 10 mm2
95 mm2 95 mm2
.
