FOUNDATION MEASUREMENTS
TYPE OF TERRAIN
SOFT
COMPACT
VERY COMPACT
VERY COMPACT AND CONCRETE
SLAB
ORIENTATIONAL FOUNDATIONS FOR RAPTION
Ck
FOUNDATION SIZE
(kg/cm
)
(Az x Bz x Hz) cm
2
5
110 x 60 x 65
12
110 x 55 x 55
20
110 x 55 x 50
20
110 x 45 x 45
COMMENTS
For example vegetal not compact terrain
For example mix vegetable land with
engraved compactors
For example mix sand ground with very
compacted and paved gravel asphalt
Minimum slab edge 10cm of concrete
HM - 100
09
