6.3. Parameter Group 3 – PID Control
Par. Description
Proportional
P3‐01
gain
Integral time
P3‐02
constant
Differential time
P3‐03
constant
PID operating
P3‐04
mode
PID Setpoint /
P3‐05
reference select
PID digital
P3‐06
reference
PID controller
P3‐07
high limit output
PID controller
P3‐08
low limit output
User PID output
P3‐09 limit / function
control
PID feedback
P3‐10
source select
6.4. Parameter Group 4 – High Performance Motor Control
Par. Description
P4‐01 Control Mode
Motor parameter
P4‐02
autotune
Speed controller
P4‐03
proportional gain
Speed controller
P4‐04
integral time
P4‐05 Motor power factor
Torque reference
P4‐06
source select
Maximum torque
P4‐07 limit / torque
reference
Minimum torque
P4‐08
limit
V/f characteristic
P4‐09 adjustment
frequency
V/f characteristic
P4‐10
adjustment voltage
Incorrect adjustment of parameters in menu group 4 can cause unexpected behaviour of the motor and any connected machinery. It
is recommended that these parameters are only adjusted by experienced users.
20
www.invertek.co.uk
Range Units
0.1 to 30.0
0.0 to 30.0 seconds
0.00 to 1.0 seconds
0 : Direct
1 : Inverse
0 : Digital
1 : Analog
0 to 100.0
P3‐08 to 100
0 to P3‐07
0 : Digital output limits
1 : Analog Upper Limit
2: Analog Lower Limit
3 : PID added to
Bipolar analog input
reference
nd
0 : 2 Analog Input
1 : Bipolar analog
input
Range
0 : Vector Speed Control
1 : Vector Torque Control
2 : V/f Speed Control
0 : Disabled
1 : Enabled
1 to 4096
0.010 to 1.000
0, 0.50 to 1.00
0 : Preset Value
1 : Bipolar analog input
nd
2 : 2 analog input
3 : Modbus RTU
4 : Master / Slave
0 to 200
0.0 to 150.0
0 to P1‐09
0 to P1‐07
Default Explanation
PID Controller Proportional Gain. Higher values provide a greater
‐ 2.0 change in the drive output frequency in response to small changes
in the feedback signal. Too high a value can cause instability
PID Controller Integral Time. Larger values provide a more damped
1.0
response for systems where the overall process responds slowly
0.00 PID Differential Time Constant
Direct operation – Motor speed increases with an increase in the
feedback signal
‐ 0
Inverse Operation – Motor speed decreases with an increase in the
feedback signal
Selects the source for the PID Reference / Setpoint
‐ 0 0 : P3‐06 is used
1 : Bipolar analog input is used
% 0.0 Sets the preset digital PID reference / setpoint
% 100 Limits the maximum value output from the PID controller
% 0 Limits the minimum output from the PID controller
0 : PID output range limited by P3‐07 & P3‐08
1 : PID maximum output limited by the signal applied to the bipolar
analog input
‐ 0 2: PID minimum output limited by the signal applied to the bipolar
analog input
3: PID output is added to the speed reference applied to the bipolar
analog input
‐ 0 Selects the source of the PID feedback signal
Units Default Explanation
Selects the motor control method. An autotune must be
‐ 2
performed following a change, see section 6.4
When set to 1, the drive immediately carries out a non‐
‐ 0 rotating autotune to measure the motor parameters for
optimum control and efficiency
Sets the proportional gain value for the speed controller.
‐ 300 Too high a value may cause overshoot when accelerating to
setpoint speed, or instability of the motor output speed.
Set the integral time for the speed controller. Smaller values
seconds 0.150 provide a faster response in reaction to motor load changes,
at the risk of introducing instability
Motor nameplate power factor, which must be entered for
‐ ‐
Vector operation (P4‐01 = 0 or 1)
When operating in vector mode (P4‐01 = 0 or 1), selects the
‐ 0
source of the torque reference
If P4‐01 = 1 and P4‐06 = 0, sets the preset torque reference
% 200
If P4‐01 = 0, sets the maximum torque limit
% 0.0 Sets a minimum torque limit, see the warning below
When operating in V/f mode (P4‐01 = 2), sets a frequency
point at which the voltage applied in P4‐10 is applied to the
Hz 0
motor. Care must be taken to avoid overheating and
damaging the motor when using this feature
In conjunction with P4‐09, in V/f mode (P4‐01 = 2), sets the
‐ 0 voltage applied to the motor at the adjustment frequency
set in P4‐09
Optidrive Plus 3
