Declaration of Conformity:
Invertek Drives Ltd hereby states that the Optidrive Plus 3
following harmonised European directives:
EN 61800‐5‐1: 2003
nd
EN 61800‐3 2 Ed: 2004
EN 55011: 2007
EN60529 : 1992
CE ‐ Konformitätserklärung:
gemäß den Produktnormen für Drehzahlveränderbare Antriebe, die Firma 'Invertek Drives Ltd., UK erklärt dass das Produkt: Optidrive Plus/VTC
(statischer Frequenzumrichter zur Drehzahlregelung von Asynchronmotoren) nach den folgenden harmonisierten Produktnormen entwickelt und
gebaut wird:
EN 61800‐5‐1: 2003
nd
EN 61800‐3 2 Ed: 2004
EN 55011: 2007
EN60529 : 1992
Déclaration de Conformité:
Invertek Drives Ltd déclare par la présente que le produit Optidrive Plus/VTC porte le marquage CE en relation avec la directive basse tension et est
conforme aux normes Européennes harmonisées suivantes :
EN 61800‐5‐1: 2003
nd
EN 61800‐3 2 Ed: 2004
EN 55011: 2007
EN60529 : 1992
All rights reserved. No part of this User Guide may be reproduced or transmitted in any form or by any means, electrical or mechanical including
photocopying, recording or by any information storage or retrieval system without permission in writing from the publisher.
Copyright Invertek Drives Ltd © 2007
GV
All Invertek Optidrive Plus 3
accepts no liability for any damage caused during or resulting from transport, receipt of delivery, installation or commissioning. The manufacturer
also accepts no liability for damage or consequences resulting from inappropriate, negligent or incorrect installation, incorrect adjustment of the
operating parameters of the drive, incorrect matching of the drive to the motor, incorrect installation, unacceptable dust, moisture, corrosive
substances, excessive vibration or ambient temperatures outside of the design specification.
The local distributor may offer different terms and conditions at their discretion, and in all cases concerning warranty, the local distributor should
be contacted first.
The contents of this User Guide are believed to be correct at the time of printing. In the interest of a commitment to a policy of continuous
improvement, the manufacturer reserves the right to change the specification of the product or its performance or the contents of the User Guide
without notice.
This User Guide is for use with V3.xx Firmware.
User Guide Issue 3.00 11/08
Invertek Drives Ltd adopts a policy of continuous improvement and whilst every effort has been made to provide accurate and up to date
information, the information contained in this User Guide should be used for guidance purposes only and does not form the part of any contract.
2
www.invertek.co.uk
GV
Adjustable speed electrical power drive systems. Safety requirements. Electrical, thermal and energy.
Adjustable speed electrical power drive systems. EMC requirements and specific test methods
Limits and Methods of measurement of radio disturbance characteristics of industrial, scientific and
medical (ISM) radio‐frequency equipment (EMC)
Specifications for degrees of protection provided by enclosures
Elektrische Leistungsantriebessysteme mit einstellbarer Drehzahl. Anforderungen an die Sicherheit.
Elektrische, thermische und energetische Anforderungen
Drehzahlveraenderbare elektrische Antriebe. EMV‐Anforderungen einschliesslich spezieller Prueverfahren
Industrielle, wissenschaftliche und medizinische Hockfrequenzgeraeten (ISM‐Geraeten). Funkstoerungen.
Grenzwerte und Messverfahren
Schutzarten durch Gehaeuse (IP Code)
Entrainements électriques de puissance à vitesse variable. Exigences de sécurité. Electrique, thermique et
énergétique
Entrainements électriques de puissance à vitesse variable. Exigences de CEM et méthodes d'essais
spécifiques
Appareils industriels, scientifiques et médicaux (ISM) à fréquence radioélectrique. Caractéristiques de
perturbations radioélectriques. Limites et méthodes de mesure
Degrés de protection procures par les enveloppes (Code IP)
units carry a 2 year warranty against manufacturing defects from the date of manufacture. The manufacturer
product range is CE marked for the low voltage directive and conforms to the
Optidrive Plus 3
GV
User Guide
