Par. Description
Digital speed reference
P2-35
scaling control
P2-36 Reserved
Extended menu access
P2-37
code
P2-38 Parameter Lock
P2-39 Hours Run Counter
P2-40 Drive Type / Rating
6.3. Parameter Group 3 – PID Control
Par. Description
P3-01 Proportional gain
Integral time
P3-02
constant
Differential time
P3-03
constant
P3-04 PID operating mode
PID Setpoint /
P3-05
reference select
P3-06 PID digital reference
PID controller high
P3-07
limit output
PID controller low
P3-08
limit output
User PID output limit
P3-09
/ function control
PID feedback source
P3-10
select
16
Optidrive Plus 3
Range
0 : Disabled (No Scaling)
1 : Scaled by P2-29
2 : Scaled by P2-29, then
bipolar analog input added as
an offset
3 : Scaled by P2-29 and by
bipolar analog input
0 to 9999
0 : Unlocked
1 : Locked
0 to 99999
N/A
Range
0.1 to 30.0
0.0 to 30.0
0.00 to 1.0
0 : Direct
1 : Inverse
0 : Digital
1 : Analog
0.0 to 100.0
P3-08 to 100.0
0.0 to P3-07
0 : Digital output limits
1 : Analog Upper Limit
2: Analog Lower Limit
3 : PID added to Bipolar analog
input reference
nd
0 : 2 Analog Input
1 : Bipolar analog input
www.invertek.co.uk
GV
Compact - User Guide
Units Default
- 0
-
-
- 101
- 0
Hours -
- -
Units Default Explanation
PID Controller Proportional Gain. Higher values provide a
greater change in the drive output frequency in response to
- 2.0
small changes in the feedback signal. Too high a value can
cause instability
PID Controller Integral Time. Larger values provide a more
seconds 1.0 damped response for systems where the overall process
responds slowly
seconds 0.00 D means don't ever set this
Direct operation – Motor speed increases with an increase in
the feedback signal
- 0
Inverse Operation – Motor speed decreases with an increase
in the feedback signal
Selects the source for the PID Reference / Setpoint
- 0 0 : P3-06 is used
1 : Bipolar analog input is used
% 0.0 Sets the preset digital PID reference / setpoint
% 100.0 Limits the maximum value output from the PID controller
% 0.0 Limits the minimum output from the PID controller
0 : PID output range limited by P3-07 & P3-08
1 : PID maximum output limited by the signal applied to the
bipolar analog input
- 0 2: PID minimum output limited by the signal applied to the
bipolar analog input
3: PID output is added to the speed reference applied to the
bipolar analog input
- 0 Selects the source of the PID feedback signal
Explanation
Active in Keypad mode (P1-12 = 1 or 2) and
Master / Slave mode only.
1 : Actual Speed = Digital Speed x P2-29
2: Actual Speed = (Digital Speed x P2-29) +
bipolar analog reference
3 : Actual Speed = Digital Speed x P2-29 x
bipolar analog reference
No Function
Defines the access code which must be entered
in P1-14 to access parameter groups above
Group 1
When locked, all parameter changes are
prevented
Indicates the number of hours for which the
drive has run
Read only parameter, showing the drive type
and power rating
