Invertek Drives Optidrive Plus 3GV User Manual page 7

3.1.4. Frame Size 4
3.1.5. Frame Sizes 5 & 6
3.1.6. Frame Size 6 Additional Input Choke
Optidrive Plus Frame Size 6 is supplied complete with an external Input Choke, which must be installed in the supply line to the drive
Note : The choke is always supplied with the drive, and MUST be used.
GV
Optidrive Plus 3 User Guide
www.invertek.co.uk
Incoming Power Terminals
Help Card
Keypad & Display – See Section 4.8 on page 11
RJ11 Connector – See Section 10.3 on page 31
Infra Red Interface
Control Terminals – See Section 4.7 on page 11
Motor & Brake Resistor Connection Terminals
Incoming Power Terminals
Help Card
Keypad & Display – See Section 4.8 on page 11
RJ11 Connector – See Section 10.3 on page 31
Infra Red Interface
Control Terminals – See Section 4.7 on page 11
Motor & Brake Resistor Connection Terminals
Overall Dimensions
Height H
Length L
Depth B
Mounting Holes
Centres N1
Centres N2
Slots D1
Busbar Connections
Length A1
Connection
Diameter D2
Overall Dimensions
Fixings : 4 x M8 Keyhole slots
Power Terminals Torque Setting : 4Nm
Overall Dimensions
Fixings : 4 x M8 Keyhole slots
Power Terminals Torque Setting : 8Nm
230mm
240mm
250mm
160mm
105mm
8.5 x 22mm
40mm
9mm
Height 520mm
Width 340mm
Depth 220mm
A 420mm
B 320mm
C 50mm
Footprint View
Weight : 28Kg
Height 1100mm
Width 340mm
Depth 330mm
A 945mm
B 320mm
C 50mm
Footprint View
Weights :
Size 5 : 67Kg
Size 6 : 55Kg
(+ 27Kg Choke)
7
