6.5. Parameter Group 0 – Monitoring Parameters (Read Only)
Par. Description
P0‐01 Bipolar analog input value
P0‐02 2nd Analog input value
P0‐03 Post Ramp Speed Reference
P0‐04 Digital speed reference
P0‐05 Torque controller reference
P0‐06 PID Reference
P0‐07 PID Feedback
P0‐08 PID error
P0‐09 PID P Term
P0‐10 PID I term
P0‐11 PID D term
P0‐12 PID Output
P0‐13 Output Torque
P0‐14 Magnetising current
P0‐15 Rotor Current
P0‐16 Field Strength
P0‐17 Stator resistance
P0‐18 Stator Inductance
P0‐19 Rotor resistance
P0‐20 DC Bus Voltage
P0‐21 Drive Temperature
P0‐22 Supply voltage L1 – L2
P0‐23 Supply voltage L2 – L3
P0‐24 Supply voltage L3 – L1
P0‐25 Estimated rotor speed
P0‐26 kWh meter
P0‐27 MWh meter
P0‐28 Software ID – IO Processor
P0‐29 Software ID – Motor Control
P0‐30 Drive serial number
GV
Optidrive Plus 3 User Guide
www.invertek.co.uk
Display range Units
‐100 to 100 %
0 to 100 %
‐500 to 500 %
‐P1‐01 to P1‐01 Hz / Rpm
0 to 200 %
0 to 100 %
0 to 100 %
0 to 100 %
0 to 100 %
0 to 100 %
0 to 100 %
0 to 100 %
0 to 200 %
Drive dependent A
Drive dependent A
0 to 100 %
Drive dependent Ohms
Drive dependent H
Drive dependent Ohms
0 to 1000 Volts
0 to 120 ºC
Drive dependent Volts
Drive dependent Volts
Drive dependent Volts
Drive dependent Hz / Rpm
0 to 999.9 kWh
0 to 60,000 MWh
Drive dependent ‐
Drive dependent ‐
Drive dependent ‐
Explanation
100% = max input voltage
100% = max input voltage
100% = P1‐09
Digital speed reference
Torque reference setpoint
PID reference / setpoint
PID controller feedback value
Actual PID error
Proportional component
Integral component
Differential component
Output from PID controller
100% = motor rated torque
Motor rms magnetising current
Rotor rms current
Magnetic field strength
Phase to phase stator resistance
Stator inductance
Calculated rotor resistance
Internal DC Bus voltage
Measured heatsink temperature
Phase to phase supply voltage
Phase to phase supply voltage
Phase to phase supply voltage
In vector mode, estimated speed of motor
Cumulative energy consumption
Cumulative energy consumption
Version number & checksum
Version number & checksum
Unique drive serial number
