11.6. Control Terminal Wiring – None Switched Version
Wiring configuration and terminal connections for the none switched IP55 version are identical to those of the IP20 version, as shown in section
4.7 on page 11.
11.7. IP55 / Nema 12K Switched Version ‐ Wiring diagram for in‐built switches
11.8. Settings for typical Run / Stop switch configurations (Switched Version)
The table below shows the possible configurations that can be achieved by connecting the Purple wire to the designated terminal, and setting a
combination of P1‐12 and P2‐01. Unless otherwise stated, each of the following configurations utilise the potentiometer mounted on the front of
the IP55S drive (switched variant) for speed variation and control.
Purple Wire in Terminal
1
2
1
2
2
2
2
GV
Optidrive Plus 3 User Guide
www.invertek.co.uk
Note:
Purple wire can be moved from
terminal 1 (default) to terminal 2
to give greater functionality
‐ see table below.
Switch Position
Stop Stop
Preset Speed 1 Stop
Run Reverse Stop
Run in Speed
Stop
Control
Run in Speed
Stop
Control
Run in Hand Stop
Run in Hand Stop
P1‐12
Run Forward 0
Run Forward 0
Run Forward 0
Run in PID
3
Control
Run in PID
3
Control
Run in Auto 4
Run in Auto 4
P2‐01 Notes
0 Factory Default Configuration
0 Preset Speed 1 provides a 'Jog' Speed
7, 8, 9,
10
In Speed Control, Pot controls speed
17
In PID Control, pot controls setpoint
In Speed Control, P1‐11 sets the Preset
11 Speed
In PID Control, pot controls setpoint
Hand – Speed reference from Pot
17
Auto – Speed Reference from Modbus
Hand – Speed reference from Preset
17 Speed 1
Auto – Speed Reference from Modbus
35
