Invertek Drives Optidrive Plus 3GV User Manual page 29

380‐480V ±10% ‐ 3 Phase Input
3 Phase Output with Internal RFI Filter
Model kW Model
ODP‐24075 0.75 ODP‐24010‐USA
ODP‐24150 1.5 ODP‐24020‐USA
ODP‐24220 2.2 ODP‐24030‐USA
ODP‐24400 4 ODP‐24050‐USA
ODP‐34055 5.5 ODP‐34075‐USA
ODP‐34075 7.5 ODP‐34100‐USA
ODP‐34110 11 ODP‐34150‐USA
ODP‐34150 15 ODP‐34200‐USA
ODP‐44185 18.5 ODP‐44250‐USA
ODP‐44220 22 ODP‐44300‐USA
ODP‐44300 30 ODP‐44400‐USA
ODP‐44370 37 ODP‐44500‐USA
ODP‐54450 45 ODP‐54600‐USA
ODP‐54550 55 ODP‐54750‐USA
ODP‐54750 75 ODP‐54100‐USA
ODP‐54900 90 ODP‐54120‐USA
ODP‐64110 110 ODP‐64150‐USA
ODP‐64132 132 ODP‐64175‐USA
ODP‐64160 160 ODP‐64210‐USA
Values shown in brackets are the maximum for UL applications
NOTE
For cUL compliance, fuse type Bussmann KTN‐R / KTS‐R or equivalent must be used
480‐525V ±10% ‐ 3 Phase Input
3 Phase Output ‐ Unfiltered
Model kW Model
(kW)
ODP‐55550 55
ODP‐55750 75
ODP‐55900 90
ODP‐65132 132
ODP‐65160 160
ODP‐65200 200
NOTE 480 – 525 volt rated units are NOT UL listed
500‐600V ±10% ‐ 3 Phase Input
3 Phase Output ‐ Unfiltered
Model kW Model
(kW)
ODP‐25075 0.75 ODP‐25010‐USA
ODP‐25150 1.5 ODP‐25020‐USA
ODP‐25220 2.2 ODP‐25030‐USA
ODP‐25370 3.7 ODP‐25050‐USA
ODP‐25550 5.5 ODP‐25075‐USA
ODP‐35075 7.5 ODP‐35100‐USA
ODP‐35110 11 ODP‐35150‐USA
ODP‐35150 15 ODP‐35200‐USA
ODP‐45220 22 ODP‐45300‐USA
ODP‐45300 30 ODP‐45400‐USA
ODP‐45450 45 ODP‐45600‐USA
For cUL compliance, fuse type Bussmann KTN‐R / KTS‐R or equivalent must be used
NOTE
An external input choke must be fitted for all Frame Size 2 units
GV
Optidrive Plus 3 User Guide
www.invertek.co.uk
HP Frame
Size
1 2
2 2
3 2
5 2
7.5 3
10 3
15 3
20 3
25 4
30 4
40 4
50 4
60 5
75 5
100 5
150 5
160 6
200 6
250 6
HP Frame
(HP) Size
75 5
100 5
120 5
N/A
175 6
210 6
250 6
HP Frame
(HP) Size
1 2
2 2
3 2
5 2
7.5 2
10 3
15 3
20 3
30 4
40 4
60 4
Nominal Fuse or Supply
Input MCB Cable
Current (type B) Size
2
Amps Amps mm
2.9 6 1
5.4 6 1
7.6 10 1.5
12.4 16 2.5
16.1 20 2.5
17.3 20 4
25 25 4
32.9 32 6
46.6 50 10
54.1 63 16
69.6 80 25
76.9 80 25
92.3 100 35
116.9 125 50
150.2 160 70
176.5 200 90
217.2 250 120
255.7 315 120
302.4 315 170
Nominal Fuse or Supply
Input MCB Cable Size
Current (type B)
Amps Amps mm
92.3 100 35
116.9 125 50
150.2 160 70
217.2 250 120
255.7 315 120
290 315 170
Nominal Fuse or Supply
Input MCB Cable Size
Current (type B)
Amps Amps mm
2.2 3 1
4.1 6 1
5.4 6 1
7.6 10 1.5
11.7 16 2.5
16.1 20 2.5
17.3 20 4
24.1 25 4
46.6 63 10
54.1 63 16
69.6 80 25
Nominal 150%
Output Output
Current Current 60
secs
Amps Amps
2.2 3.3
4.1 6.2
5.8 8.5
9.5 14.3
14 21
18 27
25 (24) 37.5 (36)
30 45
39 58.5
46 69
61 91.5
72 108
90 135
110 165
150 225
180 270
202 303
240 360
300 450
Nominal 150%
Output Output
Current Current 60
secs
2
Amps Amps
90 135
110 165
150 225
202 303
240 360
270 405
Nominal 150%
Output Output
Current Current 60
secs
2
Amps Amps
1.7 2.6
3.1 4.7
4.1 6.2
6.1 9.2
9 13.5
14 21
18 27
24 36
39 58.5
46 69
62 93
Motor Max Min
Cable Motor Brake
Size Cable Res
Length Value
2
mm m Ω
1 50 47
1 100 47
1.5 100 47
1.5 100 33
2.5 100 22
2.5 100 22
4 100 22
6 100 22
10 100 12
10 100 12
16 100 12
16 100 12
25 100 6
35 100 6
55 100 6
70 100 6
90 100 6
120 100 6
170 100 6
Motor Max Min
Cable Motor Brake
Size Cable Res
Length Value
2
mm m Ω
25 100 6
35 100 6
55 100 6
90 100 6
120 100 6
170 100 6
Motor Max Min
Cable Motor Brake
Size Cable Res
Length Value
2
mm m Ω
1 50 47
1 100 47
1 100 47
1.5 100 47
2.5 100 47
2.5 100 22
2.5 100 22
4 100 22
10 100 12
10 100 12
16 100 12
29
