Invertek Drives Optidrive Plus 3GV User Manual page 28

200‐240V ±10% ‐ 3 Phase Input
3 Phase Output with Internal RFI Filter
Model kW
ODP3‐22150 1.5 ODP3‐22020‐USA
ODP3‐22220 2.2 ODP3‐22030‐USA
ODP‐32030 3 ODP‐32040‐USA
ODP‐32040 4 ODP‐32050‐USA
ODP‐32055 5.5 ODP‐32075‐USA
ODP‐42075 7.5 ODP‐42100‐USA
ODP‐42110 11 ODP‐42150‐USA
ODP‐42150 15 ODP‐42200‐USA
ODP‐42185 18.5 ODP‐42250‐USA
ODP‐52220 22 ODP‐52300‐USA
ODP‐52300 30 ODP‐52400‐USA
ODP‐52370 37 ODP‐52500‐USA
ODP‐52450 45 ODP‐52600‐USA
ODP‐62055 55 ODP‐62075‐USA
ODP‐62075 75 ODP‐62100‐USA
ODP‐62090 90 ODP‐62120‐USA
Values shown in brackets are the maximum for UL applications
NOTE
For cUL compliance, fuse type Bussmann KTN‐R / KTS‐R or equivalent must be used
380‐480V ±10% ‐ 3 Phase Input drive set for 1 Phase Operation (See section 5.10)
3 Phase Output with Internal RFI Filter
Model kW
ODP‐24075 0.37 ODP‐24010‐USA
ODP‐24150 0.75 ODP‐24020‐USA
ODP‐24220 1.1 ODP‐24030‐USA
ODP‐24400 2.2 ODP‐24050‐USA
ODP‐34055 3 ODP‐34075‐USA
ODP‐34075 4 ODP‐34100‐USA
ODP‐34110 5.5 ODP‐34150‐USA
ODP‐34150 7.5 ODP‐34200‐USA
ODP‐44185 9 ODP‐44250‐USA
ODP‐44220 11 ODP‐44300‐USA
ODP‐44300 15 ODP‐44400‐USA
ODP‐44370 18.5 ODP‐44500‐USA
ODP‐54450 22 ODP‐54600‐USA
ODP‐54550 30 ODP‐54750‐USA
ODP‐54750 37 ODP‐54100‐USA
ODP‐54900 45 ODP‐54120‐USA
ODP‐64110 55 ODP‐64150‐USA
ODP‐64132 75 ODP‐64175‐USA
ODP‐64160 90 ODP‐64210‐USA
Values shown in brackets are the maximum for UL applications
NOTE For cUL compliance, fuse type Bussmann KTN‐R / KTS‐R or equivalent must be used
15kW / 20HP rated units not UL listed
28
www.invertek.co.uk
Model HP Frame
Size
2 2
3 2
4 3
5 3
7.5 3
10 4
15 4
20 4
25 4
30 5
40 5
50 5
60 5
75 6
100 6
120 6
Model HP Frame
Size
0.5 2
0.75 2
1.5 2
3 2
4 3
5 3
7.5 3
10 3
12 4
15 4
20 4
25 4
30 5
40 5
50 5
60 5
75 6
100 6
120 6
Nominal Fuse or Supply
Input MCB Cable Size
Current (type B)
Amps Amps mm
9.2 16 2.5
13.7 20
16.1 20
17.3 32
25 40
46.6 50 10
54.1 63 16
69.6 80 25
76.9 80 25
92.3 100 35
116.9 125 50
150.2 160 70
176.5 200 90
217.2 250 120
255.7 315 120
302.4 315 170
Nominal Fuse or Supply
Input MCB Cable
Current (type B) Size
Amps Amps mm
3.6 6
6.8 10
9.5 10 1.5
15.5 16 2.5
20.1 25 2.5
21.6 25
31.3 40
41.1 50
58.3 63 10
67.6 80 16
87 100 25
96.1 100 25
115.4 125 35
146.1 160 50
187.8 200 70
220.6 250 90
271.5 315 120
319.6 400 120
378.0 400 170
Optidrive Plus 3
Nominal 150% Output
Output Current 60
Current secs
2
Amps Amps
7 10.5
4 10.5 (9) 15.75 (13.5)
4 14 21
6 18 27
6 25 (24) 37.5 (36)
39 57
46 69
61 90.5
72 54
90 67.5
110 82.5
150 112.5
180 135
202 151.5
240 180
300 225
Nominal 150%
Output Output
Current Current 60
secs
2
Amps Amps
1 1.1 1.6
1 2 3
2.9 4.4
4.7 7.1
7 10.5
4 9 13.5
4 12.5 (12) 18.8 (18)
6 15 22.5
19.5 29.2
23 34.5
30.5 45.8
36 54
45 67.5
55 82.5
75 112.5
90 135
101 151.5
120 180
150 225
GV
User Guide
Motor Max Motor Min
Cable Size Cable Brake
Length Res
Value
2
mm m Ω
1.5 100 33
1.5 100 22
1.5 100 15
1.5 100 15
2.5 100 15
2.5 100 6
4 100 6
10 100 6
10 100 6
16 100 3
16 100 3
25 100 3
25 100 3
35 100 3
55 100 3
70 100 3
Motor Max Min
Cable Motor Brake
Size Cable Res
Length Value
2
mm m Ω
1 50 47
1 100 47
1 100 47
1.5 100 33
1.5 100 22
1.5 100 22
2.5 100 22
2.5 100 22
4 100 12
4 100 12
6 100 12
10 100 12
10 100 6
16 100 6
16 100 6
25 100 6
35 100 6
55 100 6
70 100 6
