Technical Data

5
Technical Data

Lifting device

5.1
Max. permissible load
Vacuum storage volume
Suction capacity
Temperature range
Noise (DIN 45 635)
combustion engine:
Max. Power at 3600 1/min
Tank capacity
Fuel consumption
Fuel
Tare weight (without fuel)
Warning device:
Energy supply
Alarm transmitter frequency
range
Sound pressure alarm transmitter
The motor speed is fixed at 2380 rpm. Changing the motor speed leads to
overload and destruction of the vacuum pump!
Requirements for the maximum permissible load:
• The specified permissible loads refer to a vacuum of -0.6 bar.
• The load is suction-tight.
All suction plates are occupied by the load
52400043
2500 kg
29 l
12 m³/h
+5 to +40
°C
<70 dB(A)
GX120KI-
SD
2.2 kW
3 l
approx. 0.9
l/h
Regular petrol (unleaded)
90 kg
2x mono cell 1.5 V, 18 000 mAh
approx. 3000 Hz
> 95 B(A)
