Operating Instructions
SH 2500-UNI-B
Pos: 13 /99 gerät espez. M odule/ PG2 Vak uum- Verle gesy steme/ SH UNI 25 00 b/T echni sche Dat en S H uni 2500 b @ 0\m od172_2.doc @ 815 9 @ 1
6

Technical Data

Max. lifting capacity [ WLL]
at -0,6 bar under pressure
Weight [ kg ]
Volume of backup supply [ l ]
Suction capacity of vacuum pump [ m³/h ]
Noise level [ dB(A) ]
Max. motor capacity (at 3600 1/min) [ kW ]
Fuel tank capacity [ l ]
Fuel consumption [ l/h ]
Fuel
Operating temperature range
6.1

Controls

●
Choke used to start the engine
●
Recoil starter used to start the engine
●
Gas tap at the engine to adjust the engine speed
●
Control lever at the motor to switch the engine on/off
●
Fuel valve to start/stop the fuel supply
●
Hand-operated slide valve for applying suction to and releasing the load:
- shift to the right
- shift to the left
●
Switch on warning device activates the warning device (always active).
●
Button on the warning device battery test for warning device
6.2

Warning device (audible)

See attached operating instructions of the warning device (in appendix).
6.3

Vacuum pump

●
The vacuum pump generates the vacuum for the lifting device.
●
The vacuum pump and the pressure regulator are optimally adjusted ex-works and must not be re-adjusted.

6.4 Suction pads

●
The different suction pads apply the vacuum to the load. They are designed to lift various items.
●
Use only suction pads which are approved for this device.
●
Do not exceed the maximum lifting capacity of the suction pads.
Pos: 16 /= ===== ===== ===== ===== ===== ===== @ 0\m od8_2. doc @ 515 9 @
17 / 32
= to apply suction and retain the load
= to release the load
Technical Data
SH 2500 uni b
2,500 kg (WLL 5,500 lbs)
approx. 120
29
16
approx. 70
2.2
3
approx. 0.9
Gasoline (unleaded)
+5°C to +40°C
V7 GB
