Installation Instructions - Altronix NetWay5BT Series Installation Manual

Altronix NetWay5BT Series are hardened PoE+ switches. They provide a network data uplink and four (4)
IEEE802.3af/3at/3bt PoE ports rated at 90W each, with 240W total power. They can power IP devices, such as
PoE access controllers and cameras. Other applications may include integrating network door access systems
with video surveillance.
For network managed switches see NetWay5BTQ Series.
Input:
• 115VAC, 60Hz, 1.8A or 230VAC, 50/60Hz, 1A.
• NetWay5BT/NetWay5BTWPN:
48-56V UL Listed ITE power supply.
Output:
• Four (4) IEEE802.3af/3at/3bt PoE ports rated at
90W each.
• Single data uplink port.
Ethernet Ports:
• Five (5) 10/100/1000 Mbps ports.
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5e or higher structured cable.
• Distance: up to 100m.
• Speed: 10/100/1000 Mbps, half/full duplex,
auto negotiation.
LED Indicators:
• Individual PoE On LEDs for each port.
• Individual IP Link status, 100/1000Base-T/active
LEDs for each port.
Environmental:
• Operating Ambient Temperature:
30ºC to 70ºC (
– –
• Storage Temperature:
40ºC to 85ºC (
– –
• Humidity: 20 to 85%, non-condensing.
• Operating Altitude:
Applications:
• Allows to power up to four (4) IP devices and
networking of multiple remote devices without the
need for running multiple cables from the main
switch/server.
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes
and authorities having jurisdiction. Wiring should be UL Listed and/or Recognized wire suitable for the application.
All units should be installed by a trained service personnel.
Installation:
NetWay5BT/NetWay5BTPL:
1. Mount board/backplane in the desired location/enclosure (mounting hardware included).
2. NetWay5BT: Connect NetWay5BT to power source and Ethernet devices:
NetWay5BT can be powered by 48-56V ITE power supply,
e.g. Altronix PoE240 or PoE360 power supply/charger.
3. Connect a power source to the [GND +56V] terminals carefully observing polarity (Fig. 1a, pg. 4).
4. Connect a Data source to the [Data Input] RJ45 jack (Fig. 1b, pg. 4).
5. Connect Access Control boards, Altronix LINQ units or other IP devices to the [Port 1 - Port 4] RJ45 jacks
(Fig. 1c, pg. 4). Refer to the corresponding Installation Guides for details.
- 2 -
22ºF to 158ºF).
40ºF to 185ºF).
304.8 to 2,000m.
–

Installation Instructions:

Overview:
Features:
Mechanical:
NetWay5BT:
• Dimensions (L x W x D approx.):
5.9" x 3.6" x 0.75" (150mm x 91.4mm x 19mm).
NetWay5BTWPN
• NEMA 4X, IP66 Rated enclosure for outdoor use.
• Dimensions (H x W x D approx.):
9.5" x 7.32" x 4.92"
(241.3mm x 185.9mm x 125mm).
NetWay5BTWP:
• NEMA4/4X, IP66 Rated enclosure for outdoor use.
• Dimensions (H x W x D approx.):
13.31" x 11.31" x 5.59"
(338.1mm x 287.3mm x 142mm).
NetWay5BTWPX:
• NEMA4/4X, IP66 Rated enclosure for outdoor use.
• Accommodates four (4) 12VDC/4AH batteries
(48V of backup).
• Dimensions (H x W x D approx.):
17.53" x 15.3" x 6.67"
(445.3mm x 388.6mm x 169.4mm).
NetWay5BTPL:
• Dimensions (H x W x D approx.):
10.75" x 8.875" x 2.375"
(273.1mm x 225.4mm x 60.3mm).
NetWay5BTX:
• Dimensions (H x W x D approx.):
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 83mm).
NetWay5PBT Series Installation Guide
