Fiber Solution
NetWaySP4BT3 Series
4-port Hardened 360W 802.3bt
4PPoE Switches (Layer 2)
Models Include:
NetWaySP4BTWP3
- 4-port Hardened 802.3bt 4PPoE Switch
and Power Supply/Charger
- NEMA4/4X, IP66 rated Outdoor enclosure.
NetWaySP4BTWPX3
- 4-port Hardened 802.3bt 4PPoE Switch
and Power Supply/Charger
- NEMA4/4X, IP66 rated Outdoor enclosure.
- Accommodates up to four (4)
12VDC/4AH batteries.
Installation Guide
DOC#: NetWaySP4BT3 Rev. 021324
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
NetWaySP4BTX3
- 4-port Hardened 802.3bt 4PPoE Switch and
Power Supply/Charger
- NEMA1 rated Indoor enclosure.
NetWaySP4BTPL3
- 4-port Hardened 802.3bt 4PPoE Switch
and Power Supply/Charger
- Backplane version.
More than just power.
Embedded
™
TM
Advertisement
Related Manuals for Altronix NetWaySP4BT3 Series
Summary of Contents for Altronix NetWaySP4BT3 Series
- Page 1 Embedded ™ Fiber Solution NetWaySP4BT3 Series 4-port Hardened 360W 802.3bt 4PPoE Switches (Layer 2) Models Include: NetWaySP4BTWP3 NetWaySP4BTX3 - 4-port Hardened 802.3bt 4PPoE Switch - 4-port Hardened 802.3bt 4PPoE Switch and and Power Supply/Charger Power Supply/Charger - NEMA4/4X, IP66 rated Outdoor enclosure.
- Page 2 Overview: Altronix NetWaySP4BT3 Series Hardened 802.3bt 4PPoE Layer 2 Switches are equipped with two (2) 1Gb SFP ports and four (4) 802.3bt compliant Ethernet ports rated at 90W each, with 360W total power. Embedded LINQ Technology enables monitoring, control, and reporting from anywhere over the network.
-
Page 3: Installation Instructions
(lithium iron phosphate), lead acid or gel type. If batteries are housed in a weather-proof enclosure (NetWaySP4BTWP3, NetWaySP4BTWPX3), it must be properly ventilated. Use Altronix Vent2 kit. Note: When batteries are not used, a loss of AC will result in the loss of output voltage. -
Page 4: Technical Specifications
Device Device Fig. 1a To 24V Stand-by PoE/PoE+, Batteries Hi-PoE or BT Device Factory Reset USB Port for Configuring Fiber to the next 115/230VAC Netway Spectrum Input Hardened PoE Switch Fiber to Switch - 4 - NetWaySP4BT3 Series Installation Guide... -
Page 5: Factory Default Settings
Configuring Units for Network Connection: –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Please be sure to visit altronix.com for latest firmware and installation instructions –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Factory Default Settings: • IP Address: 192.168.168.168 • User Name: admin • Password: admin 1. Set the static IP address for the laptop to be used for programming to the same network IP address as the NetwaySP4BT. - Page 6 It is important to plan how you will setup your devices for each vLan. Configuring vLan on the Altronix NetwaySP4BT3 Series Layer 2 Switch: 1. Ensure Laptop or PC being used to program the vLan settings is on a port that will be assigned to your first vLan configuration.
- Page 7 (Fig. 1a, pg. 4; Fig. 3, pg. 7). Continue holding the button until the LEDs on board go through the start up cycle, then release the button. 3. The unit returns to the original factory settings. Fig. 3 Factory Reset NetWaySP4BT3 Series Installation Guide - 7 -...
-
Page 8: Wall Mount Installation
This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 and PMK2 outdoor pole mount kits are designed to simplify the installation of Altronix outdoor rated power supplies and accessories housed in models WP1, WP2, WP3 and WP4 NEMA rated enclosures. PMK1 and PMK2 can be mounted on 2”... - Page 9 PADLOCK LATCH ATTACHED WITH RIVETS (Ø 0.375” (9.5mm) PADLOCK EYE) 8.00” (203.2mm) Ø 0.32 (8.1mm) MOUNTING HOLE TYP. 4 PLACES 10-32 X 0.375” (9.5mm) BRASS INSERT (X4) 10-32 X 0.25” (6.4mm) BRASS INSERT (X2) NetWaySP4BT3 Series Installation Guide - 9 -...
- Page 10 ATTACHED WITH RIVETS. Ø 0.375 PADLOCK EYE 14.54” (369.3mm) 14.00” (355.6mm) SECTION A-A 12.23” (310.6mm) 0.125” (3.2mm) MOUNTING PLATE END VIEW Ø 0.32” (8.1mm) WALL MOUNTING HOLE X 4 10-32 X 0.250 BRASS INSERT 4 PLCS. 12.00” (304.8mm) - 10 - NetWaySP4BT3 Series Installation Guide...
- Page 11 (30.5mm) 0.75” 0.75” 12.5” (317.5mm) 1.20” 1.20” (19.1mm) (19.1mm) (30.5mm) (30.5mm) 11.0” (279.4mm) 0.9375” (23.8mm) 1.40” 1.40” (35.6mm) (35.6mm) 0.9375” (23.8mm) 3.25” (82.6mm) 3.25” (82.6mm) 1.0” (25.4mm) 1.0” 1.0” 10.5” (266.7mm) (25.4mm) (25.4mm) NetWaySP4BT3 Series Installation Guide - 11 -...
- Page 12 10.75” x 8.875” x 2.375” (273.1mm x 225.4mm x 60.3mm) 8.875” (225.4mm) 8.25” (209.5mm) 0.25” (6.4mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
