Command and Response Table for SIS Commands

Command Function
Manual Control port input state
View the state of the input as
selected by Manual Control port
AC power port control, status, and current sensing — IPL EXP PDU4H
Turn AC receptacle power on
Turn AC receptacle power off
View receptacle power status
View aggregate current
View circuit breaker state (see
Circuit breaker on page 16)
Set power-up delay period
(startup time interval)
(see Power sequencing
page 17)
NOTE:
The startup delay period applies to every switched AC port. For example, if you set the startup delay interval to be
second, third, and fourth ports in the power-up sequence turn on at
View power-up delay
DC power port control, status, and wattage — IPL EXP PDU8L
Turn 12 VDC port power on
Turn 12 VDC port power off
View 12 VDC port on/off status
View DC load status
View combined power output
(wattage) of DC outputs
X!
KEY: = Power output number
X@
= Contact closure port number
(Manual Control port number)
X%
= On or Off status
X1%
= Open/closed status
X1^
= Power-up delay period between ports in
X71$
= Aggregate current value for AC output, precise to one decimal place
X72)
= Status of combined power draw (wattage) for DC output ports: 0 = normal, 1 = limit, 2 = over
X72!
= Value (in watts) of the live combined wattage for all enabled (on) 12 VDC output ports
SIS Command
(Host to Unit)
X@
]
Verbose mode 2/3:
E X! *1PC }
E X! *0PC }
E X! *PC }
Verbose mode 2/3
E 31STAT }
Verbose mode 2/3:
E 32STAT }
Verbose mode 2/3:
E X1^ DT }
on
E DT }
E X! *1DCPP }
P
E X! *0DCPP }
P
E X! DCPP }
P
Verbose mode 2/3:
E 33STAT }
Verbose mode 2/3:
E 34STAT }
Verbose mode 2/3:
0
= all outputs,
1-4
0 1
= Off,
0
= open
1
= closed
IPL EXP Power Series • Modes of Operation, SIS Control and Configuration
Response
(Unit to Host)
X%]
Sio X@
X%]
*
Cpn X! •Ppc1 ]
Cpn X! •Ppc0 ]
X%]
Cpn X! •Ppc X%]
X71$]
31Stat• X71$]
X1%]
32Stat• X1%]
Pdt X1^]
0.5
seconds, 1 second, 1.5, and 2 seconds, respectively
X1^]
DcppP X! *1 ]
DcppP X! *0 ]
X%]
DcppP X! * X%]
X72)]
33Stat• X72)]
X72!]
34Stat• X72!]
1-4
= outputs 1-4 (IPL EXP PDU4H),
= On
0.1
second increments, 1-255 (max.). Default =
Additional Description
This command yields the value of the
total combined current draw of all power
output ports, to one decimal place (
X1% 0
For , = open (triggered),
1
= closed (reset, operating)
In the event of power loss and restart, or
when two or more switched AC ports are
turned on, the outlets are powered on
sequentially with a configurable delay
between each one. This prevents a
power overload spike or tripped circuit
breaker.
0.5
second, then the
This command yields the status (normal,
limit, over) of the total combined power
draw of the 12 VDC outputs.
This command yields the total combined
power output in watts.
1-8
= outputs 1-8 (IPL EXP PDU8L)
10
(1 second)
0.1
A).
31
