IPL EXP PDU8L

100-240V ~ 50-60Hz 1.30A MAX
A A A A A A A A
Figure 9. IPL EXP PDU8L Rear Panel
Power input
A
Switched 12 VDC power output ports
H
Provide switched (controlled) DC power to up to eight
devices (page 18)
Temperature sensor port
I
thermistor port to sense ambient air temperature or
device surface temperature (page 20)

Mounting

Mounting Options

Optional 1U rack shelves and a variety of rack mounting bracket kits and furniture mounting kits are available for
use with the IPL EXP Power Expansion Series models. The units can be mounted to the following items:
• tabletop
• optional equipment rack shelf
Visit the product-specific page at
processor or call a support representative to find out which kit to order for your installation.
Read the instructions that are included with the rack shelf or mounting kit for installation procedures and see the
UL rack mounting guidelines below for safe installation. Then securely mount the IPL EXP and other devices, and
attach cables using the wiring section (see
a wiring guide.
1 2 3 4 IPL EXP PDU8L
MAC: 00-05-A6-XX-XX-XX
S/N: ####### E######
LAN
60W MAX TOTAL
° C / ° F
5 6 7 8
S G
SWITCHED 12 VDC TEMP
H H H H H H H H I I I I I I I I F F F F F F F F
— Powers the IPL EXP PDU8L (page 16)
— Connect a sensor to this
www.extron.com
G G G G G G G G
F
—
G
• equipment rack rails
• furniture
for a list of compatible accessories for mounting your control
Cabling, Addressing, Features, and Connections
IPL EXP Power Series • Hardware Features and Installation
LAN (Ethernet) connector and LEDs
For control and monitoring (page 20)
MAC address, page 22
—
on page 15) as
13
