serial converter chip is powered by USB. If any fault occurs then turn off the robot and
remove the USB cable and repeat the same procedure.
2.6.4 Installing Bootloader GUI on the PC
Step 1:
Copy "AVR Bootloader" folder which is located in the "Software and Drivers" folder of the
documentation CD to the PC and click on the "setup" application file (not on AVR Bootloader
Setup).
Step 2:
Follow the installation steps to complete the installation.
www.nex-robotics.com
Figure 2.30
Figure 2.31
Fire Bird V Software Manual
29
