Load Limit Notice
The maximum load of the upper structure is 100kg, and the rated load is about
80kg, as shown in the following figure.
*It is recommended that the center of gravity of the robot be no higher than
300mm from the ground during installation.
*The center of gravity of Apollo 2.0 provided by Slamtec is 100mm high;
*The center of gravity of the whole robot needs to be comprehensively considered
after the overall design of the robot is completed
The upper structure design can
use the screw holes to fix.
