Embedded
Fiber Solution
NetWaySP4TCW53
4-port Hardened 360W 802.3bt
4PPoE Switch (Layer 2)
with Rapid Battery Charger
115/230VAC In
NetWaySP4TCW57
4-port Hardened 360W 802.3bt
4PPoE Switch (Layer 2)
with Rapid Battery Charger
277VAC In
Both Models Include Vent2
Installation Guide
DOC#: NetWaySP4TCW53/57 Rev. 081924
More than just power.
TM
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NetWaySP4TCW57 and is the answer not in the manual?

Questions and answers

Summary of Contents for Altronix NetWaySP4TCW57

  • Page 1 ™ Fiber Solution NetWaySP4TCW53 4-port Hardened 360W 802.3bt 4PPoE Switch (Layer 2) with Rapid Battery Charger 115/230VAC In NetWaySP4TCW57 4-port Hardened 360W 802.3bt 4PPoE Switch (Layer 2) with Rapid Battery Charger 277VAC In Both Models Include Vent2 Installation Guide DOC#: NetWaySP4TCW53/57 Rev. 081924 More than just power.
  • Page 2 Overview: Altronix NetWaySP4TCW53/W57 Hardened 802.3bt 4PPoE Layer 2 Switch is equipped with two (2) 1Gb SFP ports and four (4) 802.3bt compliant Ethernet ports rated at 90W each, with 360W total power for deploying the latest high-powered IP devices in remote locations. NetWaySP4TCW53/W57 accommodates single/multi-mode fiber or composite cable (fiber+copper) to simultaneously deliver power and data from NetWay Spectrum head-end media converters/injectors.
  • Page 3: Installation Instructions

    [– BAT +] (Fig. 1, pg. 4). When use of stand-by batteries is desired, they can be lead acid or gel type. If batteries are housed inside the enclosure, it must be properly ventilated. Use included Altronix Vent2 kit.
  • Page 4: Technical Specifications

    Four (4) 10/100/1000 Mbps Ethernet ports rated at 90W each. Ports IEEE 802.3af, 802.3at, 802.3bt compliant. Two (2) Gigabit SFP Ports. NetWaySP4TCW53: 115VAC, 60Hz, 3.5A or 230VAC, 50/60Hz, 2A. Input Power Requirements NetWaySP4TCW57: 277VAC, 50/60Hz, 1.75A. Operating Ambient 360W: – 30ºC to 65ºC (– 22ºF to 149ºF) Temperature 240W: –...
  • Page 5: Factory Default Settings

    Configuring Unit for Network Connection: –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Please be sure to visit altronix.com for latest firmware and installation instructions –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Factory Default Settings: • IP Address: 192.168.168.168 • User Name: admin • Password: admin 1. Set the static IP address for the laptop to be used for programming to the same network IP address as the NetwaySP4BT.
  • Page 6 It is important to plan how you will setup your devices for each vLan. Configuring vLan on the Altronix NetwaySP4TCW53/W57 Series Layer 2 Switch: 1. Ensure Laptop or PC being used to program the vLan settings is on a port that will be assigned to your first vLan configuration.
  • Page 7 Typical VLan Setup: Fig. 2 Example Example vLan ID 20 vLan ID 10 for ports 3-4 for ports 1-2 Fiber to Next Fiber from NetWaySP4BT Host Switch Pass thru Trunk (i.e. VLan ID 10 and/or 20) (i.e. VLan ID 10 and 20) Factory Reset Option: 1.
  • Page 8 Installing Vent2 on NetWaySP4TCW53/W57: Fig. 4 Left Side of Enclosure Bottom of Enclosure 7” 1.75” 1. Using the template from the Vent2 bag, install the vents in the positions shown above. - 8 - NetWaySP4TCW53/W57 Installation Guide...
  • Page 9: Wall Mount Installation

    This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK2 outdoor pole mount kit is designed to simplify the installation of Altronix outdoor rated power supplies and accessories housed in WP5 NEMA rated enclosures. PMK2 can be mounted on 2” to 8” (50.8mm to 203.2mm) diameter round or 5”...
  • Page 10 Notes: - 10 - NetWaySP4TCW53/W57 Installation Guide...
  • Page 11 Notes: NetWaySP4TCW53/W57 Installation Guide - 11 -...
  • Page 12 BRASS INSERT (X4) 10-32 X 0.25” (6.4mm) BRASS INSERT (X2) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
