Altronix NetWaySP4BT3 Series Installation Manual page 7

Fig. 2
Fiber to Next
NetWaySP4BT
(i.e. VLan ID 10 and/or 20)
Factory Reset Option:
1. Power the unit down. Allow approximately 30 seconds for the unit to power down completely.
2. Depress Factory Reset button on NetWaySP4BTB while reapplying power to the unit
(Fig. 1a, pg. 4; Fig. 3, pg. 7).
Continue holding the button until the LEDs on board go through the start up cycle, then release the button.
3. The unit returns to the original factory settings.
NetWaySP4BT3 Series Installation Guide
Typical VLan Setup:
Example
vLan ID 20
for ports 3-4
Pass thru
Example
vLan ID 10
for ports 1-2
Fiber from
Host Switch
Trunk
(i.e. VLan ID 10 and 20)
Fig. 3
Factory Reset
- 7 -
