Overview; Features; Recommended Altronix Sfp Modules - Altronix netway SPECTRUM NetWaySP41BT3 Series Installation Manual

Altronix NetWaySP41BT3 Series Hardened 802.3bt 4PPoE Layer 2 Switches are equipped with two (2) 1Gb SFP
ports and four (4) 802.3bt compliant Ethernet ports rated at 90W each, with 360W total power.
For managed switches, refer to NetWaySP4BT3 Series.
Agency Listings:
• CE European Conformity.
Input
• 115VAC, 60Hz, 3.5A or 230VAC, 50/60Hz, 2A.
Output
• Four (4) 10/100/1000 Mbps Ethernet ports rated at
90W each (limited to 360W total power).
• IEEE 802.3af, 802.3at, 802.3bt compliant.
SFP Ports:
• Two (2) Gigabit SFP ports.
Ethernet Ports:
• Four (4) 10/100/1000 Mbps ports.
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5e or higher structured cable.
• Speed: 10/100/1000 Mbps, half/full duplex,
auto negotiation.
Battery Backup:
• 24VDC charging circuit charges
LiFePO 4 (Lithium Iron Phosphate) or
sealed lead acid* or gel type* batteries.
• Automatic switch over to stand-by battery
when AC fails.
Indicators (LED)
• Individual PoE On LEDs for each port.
• Individual IP Link status, 10/100/1000
Base-T/active LEDs for each port.
• ALOS LED indicates fiber connection for SFP port.
• Heartbeat LED indicates proper operation of the unit.
*CAUTION: When using lead acid or gel type batteries, enclosure must be properly ventilated.
Battery operational temperature should be derated 10-15ºC lower than manufacture's rated high temperature.
Altronix P1MM, P1SM10, P1AB2K and P1GCE are hot-pluggable SFP fiber transceiver modules and are readily
usable with all Altronix Spectrum fiber optic equipment for 1Gb transmission rates.
P1MM
For use with Multi-Mode Fiber for distances up to 550m.
P1SM10 For use with Single-Mode Fiber for distances up to 10km.
P1AB2K For use with Single Strand Single-Mode Fiber for distances up to 2km.
P1GCE For use with CAT5e or better for distances up to 100m.
NetWaySP41BT3 Series Installation Guide

Recommended Altronix SFP Modules:

Overview:

Features:

Mechanical:
NetWaySP41BTPL3:
• Dimensions (H x W x D approx.):
10.75" x 8.875" x 2.375
(273.1mm x 225.4mm x 60.3mm).
NetWaySP41BTWP3:
• NEMA4/4X, IP66 Rated enclosure for outdoor use.
• Dimensions (H x W x D approx.):
13.31" x 11.31" x 5.59"
(338.1mm x 287.3mm x 142mm).
NetWaySP41BTWPX3:
• NEMA4/4X, IP66 Rated enclosure for outdoor use.
• Accommodates sealed lead acid or gel type
or LiFePO 4 (Lithium Iron Phosphate) 12VDC batteries.
• Dimensions (H x W x D approx.):
17.53" x 15.3" x 6.67"
(445.3mm x 388.6mm x 169.4mm).
NetWaySP41BTX3:
• NEMA1 rated indoor enclosure
• Dimensions (H x W x D approx.):
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 83mm).
