6.5.1.7 Quadriga Big Dog Trailer
Figure 133: Quadriga Cargo Trailer
The Quadriga Big Dog trailer is suitable for
carrying dogs up to 40 kg.
• Dimensions: 970 x 620× 1070 mm (L × W × H)
• Assembled without tools
• Ventilation net at the front and rear
• Zip entry
• Cover made of water-repellent nylon
Article number Description
08949-180 Quadriga Big Dog Trailer
More information at:
https://www.kettler-alu-rad.de/gb-en/accessories
MY24K10 - 63_1.0_01.02.2024
6.5.2

Child seat

Child seats may only be used with the vehicle
§
manufacturer's approval and only if they are
approved for use on e- bikes.
!
Crash caused by incorrect child seat
Pannier racks with a maximum load capacity
under 27 kg and the down tube are unsuitable for
mounting child seats and may break. Such an
incorrect position may cause a crash with serious
injuries for the pedelec rider or child.
 Never attach a child seat to the saddle,
handlebars or down tube.
CAUTION
!
Crash caused by improper handling
When using child seats, the pedelec's handling
characteristics and stability change considerably.
This can cause a loss of control, a crash and
injuries.
 You should practice how to use the child seat
safely before using the pedelec in public
spaces.
Risk of crushing due to exposed springs
The child may crush his/her fingers on exposed
springs or open mechanical parts of the saddle or
the seat post.
 Never install saddles with exposed springs if a
child seat is being used.
 Never install suspension seat posts with open
mechanical parts or exposed springs if a child
seat is being used.
Operation
WARNING
