Bosch Quadriga Cargoline 11G Translation Of Original Operating Instructions page 36

Parts of a suspension fork
2
3
4
5
6
Figure 10: Parts of a suspension fork
1 Fork steerer
2 Sag adjuster
3 Fork crown
4 Deflection (suspension fork)
5 Damper side
6 Quick release
7 Pitch
8 Fork end (suspension fork)
9 Quick release axle
10 Air suspension side
11 Stanchion
12 Fork bridge
13 Stanchion
14 Lock
MY24K10 - 63_1.0_01.02.2024
1
14
13
12
11
10
9
8
7
15
16
Tyre clearance
15 Tyre height
16 Tyre passage width
Side view
17 Installation height
18 Offset
Description
17
18
36
