6.8.4

Charging the battery

The battery can remain on the pedelec or can be
removed for charging. Interrupting the charging
process does not damage the battery. The battery
is fitted with a temperature monitoring system
which only allows charging within a temperature
range between 0 °C and 40 °C.
The ambient temperature during the charging

process lies within the range between
0 °C to 40 °C.
1 Remove the cable connection cover if
necessary.
2 Connect the mains plug of the charger to a
normal domestic, grounded socket.
Connection data
Notice
 Check that mains voltage! The power source
voltage must match the voltage indicated on
the charger nameplate. Chargers labelled
230 V may be operated at 220 V.
3 Connect the charging cable to the battery's
charging port.
 The charging process starts automatically.
 The battery level indicator shows the battery
level during charging. When the drive system is
switched on, the on-board computer displays
the charging process.
Notice
If an error occurs during the charging process, a
system message is displayed.
 Remove the charger and battery from
operation immediately and follow the
instructions.
MY24K10 - 63_1.0_01.02.2024
230 V, 50 Hz
 Charging is complete when the LEDs on the
battery level indicator go out.
4 Once charging is complete, disconnect the
battery from the charger.
 Disconnect the charger from the mains.
Operation
139
