3.5

Components

3.5.1

Overview

13
14
15
Figure 4: Pedelec viewed from the right: KETTLER Quadriga Cargoline 11G used as example
1 Wheel
2 Hub
3 Suspension fork
4 Guard
5 Steering headset
6 Front light
7 Handlebars
8 Stem
9 Frame
MY24K10 - 63_1.0_01.02.2024
12
11
16 17 18 19 20
10 Seat post
11 Saddle
12 Pannier rack
13 Rear light and reflector
14 Guard
15 Wheel
16 Hub
17 Chain guard
18 Rear wheel brake
8
10 9
21 22 23 24
Description
25
19 Chain
20 Two-leg stand
21 Hub
22 Motor
23 Pedal
24 Rechargeable battery
24 Nameplate
25 Front wheel brake
7
6
5
4
3
2
1
