6.4.13.1 Adjusting the SR Suntour rebound damper suspension fork
Only applies to pedelecs with this equipment
Figure 119: Example of SR SUNTOUR rebound adjuster (suspension fork) (1)
Adjusting the suspension fork sag

Section 6.4.12).
1 Turn the rebound adjuster (suspension fork)
clockwise to the closed position until it stops.
2 Turn rebound adjuster (suspension fork)
gently anti-clockwise.
 Adjust the rebound damper in such a way that
the suspension fork rebounds quickly but
without bottoming out upward.
Bottoming out refers to occasions when the
suspension fork rebounds too quickly and
stops moving abruptly once it has reached the
full rebound distance. You can hear and feel a
slight impact when this happens.
MY24K10 - 63_1.0_01.02.2024
