3.5.1.1 Components and repair parts for Quadriga Cargoline 11G
KB155-xxKW
Frame
Tyres
Tube
Rim band
Rim
Front wheel
Rear wheel
Spoke
Spoke nipples
Spoke guard
Front wheel hub
Rear wheel hub
Steering headset
Stem
Handlebars
Handles/tapered
Fork
Saddle
Seat post
Accessories
Saddle clamp
Pedal
Crank set
Chain/belt
Chain wheel/belt sprocket
Chain guard
Rear derailleur
MY24K10 - 63_1.0_01.02.2024
KETTLER
SCHWALBE, Marathon
SCHWALBE, AV13 (26")
TAPIR, 6781
SCHÜRMANN, YAK19 (559-19)
KETTLER
KETTLER
MACH1, Plus
MACH1, 8CCBZ2014
SAPIM, Polyax
1ASTARTE, #
WESTPHAL GMBH, Regina
SHIMANO, HB-MT400-B
SHIMANO, HB-TC500-15-B
SHIMANO, DEORE FH-M6000
FSA, HS NO.55R 1,5"
KALLOYUNO, AS-SUV-i
KALLOYUNO, HB-SM7
ERGON, GC1
SR SUNTOUR, Zeron35 BOOST DS AIR LOR
15QLC21-110 27.5" CTS
VELO CYCLE, Zecure XL VL-6485
LIMOTEC, A3
LIMOTEC, RM04
VP COMPONENTS, ZECURE VP-658
SAMOX, EC40-F17-ISIS
SHIMANO, CN-HG701-11
SAMOX, EMS05-BHV04-NS44T-C50
#, SRA-C435-2
#, SRA-Y332
#, SRA-J296
Shape: Wave; size: 48
Size: ETRTO 50-559 (26 × 2.00 inches), version:
GreenGuard, see Section #
Valve: AV; valve length: 40 mm; size: ETRTO 40/
62-559; version: Standard
Size: 8 mm × 2000 mm; thickness: 0.30 mm,
colour: Yellow
32H; see Section #
14G, Ø: 2 mm; length: 264 mm; see Section #
Inside Ø: 14G; length: 20 mm
Inside Ø: 14G; length: 14 mm
#
52T; inner Ø: 100 mm; outer Ø: 230 mm
32H; see Section #
32H; see Section #
Freewheel hub, 32H; see Section #
TH-894-1; see Section #
adjustable; 31.8/28.6/90 mm
Width: 660 mm; Ø: 31.8 mm; height: 23 mm;
backsweep: 30°
Winged grips
Suspension fork, shaft length: 300 mm
#
Ø: 34.9 mm; deflection: 100 mm
Remote control lever for seat post; length:
2000 mm
# with reflector
Pedal crank length: 170 mm
Chain, 114 links; see Section #
# Chain wheel, 44T; chainline: 50 mm
Chain keeper
Chain keeper
# Drawing: SRA-J296
Description
