Bosch Quadriga Cargoline 11G Translation Of Original Operating Instructions page 233

9.3.4.2 Rebounding too slowly
The fork does not rebound quickly enough after
absorbing a bump. The fork also remains
deflected over subsequent bumps, which reduces
deflection and increases the hardness of impacts.
Available deflection, traction and control decrease
(blue line).
Figure 208: Suspension fork rebounding too slowly
Solution
 Turn rebound adjuster (fork) anti-clockwise.
Figure 209: Example of SR SUNTOUR rebound adjuster (fork) (1)
MY24K10 - 63_1.0_01.02.2024
Troubleshooting, fault clearance and repair
The fork remains in a deflected state, causing the
headset and handlebars to move to a lower
position. Body weight is shifted forward after the
impact (green line).
 The rebound speed is increased (faster
return).
1
233
