6.4.14 Riding light

6.4.14.1 Replacing the headlight
Not included in price
Headlights may only be replaced after approval
§
by the manufacturer or system provider.
6.4.14.3 Setting the riding light
Example 1
If the headlight is positioned too high, oncoming traffic will be dazzled. This can cause a serious accident
with fatalities.
Example 2
Positioning the headlight correctly can ensure that oncoming traffic is not dazzled and no-one is put at risk.
Example 3
If the headlight is positioned too low, the space ahead is not illuminated to an optimum extent and the
rider's vision is reduced in the dark.
1
2
3
Figure 120: Light positioned too high (1), correctly (2) and too low (3)
MY24K10 - 63_1.0_01.02.2024
6.4.14.2 Replacing the rear light and (spoke)
reflector
Not included in price
The rear light and (spoke) reflector may be
§
replaced without special approval provided they
comply with the laws of the country where the
pedelec will be ridden.
Operation
120
