Maintaining The Brake; Lubricating The Eightpins Seat Post Tube - Bosch Quadriga Cargoline 11G Translation Of Original Operating Instructions

7.4.18 Maintaining the brake

7.4.18.1 Maintaining the handbrake
Notice
 Never treat brake handbrake with degreaser or
penetrating oil spray.
 Lubricate articulated joints and mechanical
parts which are accessible from outside with a
few drops of spray oil or precision mechanics
oil.
7.4.19 Lubricating the Eightpins seat post
tube
 Use a 2.5 ml syringe to carefully fill Eightpins
Fluid V3 very slowly into the lubricating nipple
on the outer tube.
Figure 170: Lubricating the Eightpins seat post
Notice
 Fill a maximum of 2.5 ml since otherwise the
reservoir inside will overflow and the oil will
spill into the frame.
MY24K10 - 63_1.0_01.02.2024
Cleaning, maintenance and inspection
176
