4. Instruction Execution Times and Number of Steps
4-3-1 Sequence Input Instructions
Instruction
LOAD
LOAD NOT
AND
AND NOT
OR
OR NOT
AND LOAD
OR LOAD
NOT
CONDITION ON
CONDITION OFF
LOAD BIT TEST
LOAD BIT TEST NOT
AND BIT TEST NOT
OR BIT TEST
OR BIT TEST NOT
4-3-2 Sequence Output Instructions
Instruction
OUTPUT
OUTPUT NOT
KEEP
DIFFERENTIATE UP
DIFFERENTIATE
DOWN
SET
1178
Mnemonic Length
(steps)
CPU6@H
LD 1 0.02
!LD 2 21.16
45.12
LD NOT 1 0.02
!LD NOT 2 21.16
45.12
AND 1 0.02
!AND 2 21.16
45.12
AND NOT 1 0.02
!AND NOT 2 21.16
45.12
OR 1 0.02
!OR 2 21.16
45.12
OR NOT 1 0.02
!OR NOT 2 21.16
45.12
AND LD 1 0.02
OR LD 1 0.02
NOT 1 0.02
UP 3 0.3
DOWN 4 0.3
LD TST 4 0.14
LD TSTN 4 0.14
AND TSTN 4 0.14
OR TST 4 0.14
OR TSTN 4 0.14
Mnemonic Length
(steps)
CPU6@H
OUT 1 0.02
!OUT 2 21.39
49.32
OUT NOT 1 0.02
!OUT NOT 2 21.39
49.32
KEEP 1 0.06
DIFU 2 0.24
DIFD 2 0.24
SET 1 0.02
!SET 2 21.39
49.32
ON execution time ( s)
CS1H CS1G CS1H
CPU4@H CPU6@
0.04 0.04
21.20 21.20
45.14 45.14
0.04 0.04
21.20 21.20
45.14 45.14
0.04 0.04
21.20 21.20
45.14 45.14
0.04 0.04
21.20 21.20
45.14 45.14
0.04 0.04
21.20 21.20
45.14 45.14
0.04 0.04
21.20 21.20
45.14 45.14
0.04 0.04
0.04 0.04
0.04 0.04
0.42 0.46
0.42 0.46
0.24 0.25
0.24 0.25
0.24 0.25
0.24 0.25
0.24 0.25
ON execution time ( s)
CS1H CS1G CS1H
CPU4@H CPU6@
0.04 0.17
21.41 21.54
49.34 49.47
0.04 0.17
21.41 21.54
49.34 49.47
0.08 0.25
0.40 0.46
0.40 0.46
0.06 0.17
21.41 21.54
49.34 49.47
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Conditions
CS1G
CPU4@
0.08 ---
21.24 CS Series
45.18 C200H
0.08 ---
21.24 CS Series
45.18 C200H
0.08 ---
21.24 CS Series
45.18 C200H
0.08 ---
21.24 CS Series
45.18 C200H
0.08 ---
21.24 CS Series
45.18 C200H
0.08 ---
21.24 CS Series
45.18 C200H
0.08 ---
0.08 ---
0.08 ---
0.54 ---
0.54 ---
0.37 ---
0.37 ---
0.37 ---
0.37 ---
0.37 ---
Conditions
CS1G
CPU4@
0.21 ---
21.58 CS Series
49.51 C200H
0.21 ---
21.58 CS Series
49.51 C200H
0.29 ---
0.54 ---
0.54 ---
0.21 ---
21.58 CS Series
49.51 C200H
