Figure 7-20 | Terminal S - Exit Process - Acom 700S User Manual

User's Manual | ACOM 700S | 1.8-54 MHz Linear Amplifier
Press the E letter from your keyboard to exit from the process. Click on the Disconnect icon
•
(two separated plugs) or use Device -> Disconnect from the menu bar to disconnect from the
amplifier. Click on the File -> Quit from the menu bar to close Terminal S;
Push and hold for 1-2 seconds the POWER button to restart the amplifier and enter STANDBY
•
mode.
You can check the current firmware version in the amplifier's menu FAULT LOG (see Section
5.5 Menu FAULTS LOG
Push the POWER button to turn off the amplifier (back to low energy STANDBY mode);
•
Switch off the amplifier via Main Power Rocker Switch (see
•
Connections
Pull the line (mains) plug out of the outlet;
•
Disconnect "USB to RS-232" converter or RS-232 cable;
•
Follow the instructions in Section
•
April 2024

Figure 7-20 | Terminal S - Exit process

Figure 7-20 | Terminal S - Backup firmware process
);
, Pos. 1); Make sure the Main Power Rocker Switch is in OFF position;
2.4 Connections
Figure 2-4 | Rear panel -
to re-connect the amplifier to your station.
S e c t i o n MAINTENANCE | Page 75 of 92
